Peripheral

• Accessory Connections

• RSA/NATO ports
  1/4"-20 mounting hole
  Cold shoe mount
  Video transmission/follow focus motor port (USB-C)
  RSS camera control port (USB-C)
  Follow focus motor port (USB-C)


• Battery

• Model: BG30-1950mAh-15.4V
  Type: LiPo 4S
  Capacity: 1950 mAh
  Power: 30.03 Wh
  Max. Battery Life: 12 h
  Charging Time: 1.5 h (24W USB adapter using the QC 2.0 or PD protocol)
  Suggested Charging Temperature: 5°C to 40°C

• Connections

• Bluetooth 5.0; USB-C

• Mobile Assistant Software Requirements

• iOS 11 or above;
  Android 7.0 or above

• Languages supported by the touchscreen

• English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

Working Performance

• Tested Payload

• 4.5 kg (10.0 lbs)

• Maximum Controlled Rotation Speed

• Pan: 360°/s
  Tilt: 360°/s
  Roll: 360°/s

• Mechanical Endpoint Range

• Pan axis control: 360° continuous rotation
  Roll axis control: -95° to +240°
  Tilt axis control: -112° to +214°

Mechanical & Electrical Characteristics

• Operating Frequency

• 2.4000 GHz - 2.4835 GHz

• Transmission Power

• <8 dBm

• Operating Temperature

• -20° to 45° C (-4° to 113° F)

• Weight

• Gimbal: Approx. 960 g (2.12 lbs) (excluding the Quick-Release Plates and Camera Mounting Plate)
  Camera Mounting Plate: Approx. 150 g (0.33 lbs)
  BG30 Grip: Approx. 265 g (0.58 lbs)
  Extended Grip/Tripod: Approx. 226 g (0.50 lbs)
  Upper and Lower Quick-Release Plates: Approx. 105 g (0.23 lbs)

• Gimbal Dimensions

• Folded: 260×265×70 mm (excluding the BG30 grip)
  Unfolded: 410×260×195 mm (including the BG30 grip, excluding the extended grip/tripod)
